LED Spotlight
ZY8302 Series
  • IP Code: IP66
  • Ambient temp.: -40℃ to +50℃
  • It can be used as spotlight in factory, construction site and some other indoor or outdoor places.
  • It efficiently utilize the light to 95%.Glare free, have a good performance of illuminance uniformity. Operator can choose the beam angle according to the application.
  • It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide lamp.
  • The light source is separated from the electrical appliance. This split style with the high efficiency radiator have solved the heating-up problem so that ensure the 100,000 hours LED lifespan.
  • Equipped with world top ranking brand, Taiwan Meanwell electrical appliance with power factor 0.98, make the lamp's performance more stable and efficient.
  • The locking device on the bracket will keep the lamp from shift or trembling during harsh vibration.
  • The housing adopts high-tech surface spraying technology, abrasion resistance corruption, waterproof, dustproof, suitable to be used at all kinds of environments.
  • Quick opening lid, easy to maintain.
  • Floodlight beam angle is available according to customers' requirement.
TECHNICAL SPECIFICATION
Input Voltage 90-305VAC / 127-431VDC
Output Voltage 54VDC
Frequency 50Hz / 60Hz
Ingress Protection IP66
Anti corrosion grade WF2
Insulation Grade I
Space Height Ratio 1.8
Thread G3/4"
Leading-in cable diameter Φ10mm -Φ12mm
Dimension Φ380x270mm
Net Weight 8Kg
ORDERING REFERENCE
Ordering Reference Light Source Rated Wattage Light Output Metal Halide Electrodeless High Pressure Mercury
ZY8302-L60

LED
60 8,194 150W 135W 175W
ZY8302-L80 80 10,016 175-250W 165W 250W
ZY8302-L100 100 11,568 250W 200W 250-400W
ZY8302-L120 120 13,310 250-400W 250W 400W
